A10A AI Supercomputing Workstation

Specifications

• Hardware Platform: AMD Ryze…Supplier claim
• AI Compute: 126 TOPS,up to 96 G…Supplier claim
• Representative Models: A10A /…Supplier claim
• Hardware Platform: AMD Ryzen™ AI Max+ 395Supplier claim
• AI Compute: 126 TOPS, up to 96 GB allocatable VRAMSupplier claim
• Size: 158.5*158.5*80mmSupplier claim
• CPU: AMD Ryzen™ AI Max+ 395 / AMD Ryzen™ AI Max+ PRO 495Supplier claim
• RAM: 128GB LPDDR5X, Up to 192GBSupplier claim
• ROM: M.2 2280 NVMe*2Supplier claim
• I/O: USB-A*4;Type-C*2;HDMI*1;DP*1;RJ45*2(2.5G);OCulink*1; AUDIO*1;DMIC *4;2W/4ohm*2; Phone Jack*1; DC Jack*1Supplier claim
• OS: Windows11/LinuxSupplier claim
• RAM: LPDDR5X ；up to 128GBSupplier claim
• ROM: Up to 8TB ; M.2 2280 Nvme*2Supplier claim
• Size: 158.5*158.5*80mmSupplier claim
• Mat.: PC+ABS+MetalSupplier claim
• Product - Product Type: Mini pcSupplier claim
• CPU - PCBA Model: P10-F11-21 || P10-F11-21Supplier claim
• Model - Ryzen™ AI Max+ 395: Ryzen™AI Max+ PRO 495Supplier claim
• manufacturing process - TSMC 4nm FinFET: TSMC 4nm FinFETSupplier claim
• core - 16 Cores 32Threads: 16 Cores 32ThreadsSupplier claim
• cache - L2：16 MB L3：64 MB: L2：16 MB L3：64 MBSupplier claim
• Maximum speed - 5.1 GHz: 5.2 GHzSupplier claim
• power wastage - 120 W: 120 WSupplier claim
• Chipsets - PCH: / || /Supplier claim
• GPU - Model: Radeon 8060S Graphics || Radeon 8065S GraphicsSupplier claim
• core - 40: 40Supplier claim
• speed - 2900 MHz: 3000 MHzSupplier claim
• resolution - 7680x4320 @ 60Hz: 7680x4320 @ 60HzSupplier claim
• NPU - NPU TOPS: Up to 50 TOPS || Up to 55 TOPSSupplier claim
• Memory - Model: Onboard LPDDR5X*4CH 496ball || Onboard LPDDR5X*4CH 496ballSupplier claim
• speed - Up to 8000 MT/s: Up to 8533 MT/sSupplier claim
• Capacity - Up to 128G: Up to 128GSupplier claim
• Storage - SSD Capacity: Up to 2TB*2Supplier claim
• SSD Type - M.2_M_Key_x4_2280 NVME*1 Gen4.0*1 M.2_M_Key_x1_2280 NVME*1 Gen4.0*1: M.2_M_Key_x4_2280 NVME*1 Gen4.0*1 M.2_M_Key_x1_2280 NVME*1 Gen4.0*1Supplier claim
• RTC - BIOS Support: Real-time clock, timed power-onSupplier claim
• power-on - BIOS Support: Support the automatic power on function after power-onSupplier claim
• diskless network - BIOS Support: Support UEFI diskless bootSupplier claim
• TPM - CPU Integrated TPM: TPM 2.0 is supportedSupplier claim
• multi-screen - video output: The system supports HDMI*1+DP*1+type_c*2 four-screen simultaneous displaySupplier claim
• LED - status indicator: Power on white light, standby white light breathing, power off light off,Reserved interface for ambient lightingSupplier claim
• WIFI - Model: M.2 E_Key (wifi5/6/7)Supplier claim
• Bluetooth - Model: usbSupplier claim
• 3G - built-in: NOSupplier claim
• 4G - built-in: NOSupplier claim
• Ethernet - LAN1: 10M/100M/1000M/2.5Gbps self-adaptiveSupplier claim
• USB2.0 - Front USB2.0: NOSupplier claim
• USB3.0 - Front USB3.0: USB3.2 GEN2 Type-A*2 10Gbps 5V/1A || USB3.2 GEN2 Type-A*2 10Gbps 5V/1ASupplier claim
• Rear USB3.0 - USB3.2 GEN1 Type-A*2 5Gbps*2 5V/1A: USB3.2 GEN1 Type-A*2 5Gbps*2 5V/1ASupplier claim
• TF - Expanded External Storage: NOSupplier claim
• HDMI - video output: HDMI 2.1 *1 TMDS Max：4096*2160@60Hz || HDMI 2.1 *1 TMDS Max：4096*2160@60HzSupplier claim
• DP - 4K audio and video output: DP 2.1 *1 Max：4096*2160@60Hz || DP 2.1 *1 Max：4096*2160@60HzSupplier claim
• VGA - video output: NOSupplier claim
• COM - serial port: NOSupplier claim
• RJ45 - Gigabit Ethernet: * 2Supplier claim
• LVDS - screen interface: NOSupplier claim
• Type C - Front Type-C: DP 2.1 + USB4 *1 40 Gbps, supports 15 W (5 V/3 A) || DP 2.1+ USB4 *1 40 Gbps, supports 15 W (5 V/3 A)Supplier claim
• Rear Type-C - DP 2.1 + PD + USB4 × 1, 40 Gbps; supports PD 15 W: DP 2.1 + PD + USB4 × 1, 40 Gbps; supports PD 15 WSupplier claim
• panel switch - Power Button: Power Button*1Supplier claim
• Reset - Reset: Clear CMOS*1Supplier claim
• DC IN - Power Supply Input: DC Jack *1 5.5/2.5mmSupplier claim
• Audio-in/out - Audio-out: 3.5mm Line Out Jack x 1（ Postscript）Supplier claim
• Oculink - Oculink: *1 PCIE4.0_x4 || *1 PCIE4.0_x4Supplier claim
• One-click AI - copilot: Reserved Interface*1 Pre-installed AI meeting assistant, local knowledge base, and other software (to be confirmed)Supplier claim
• UART serial port - serial output: NOSupplier claim
• Antenna - FPC Antenna 1: WiFi 2.4+5G+BT *1Supplier claim
• SIM - micro SIM: NOSupplier claim
• OS - Version: Windows 11/LinuxSupplier claim
• Environment - Working Temperature: 0~40℃Supplier claim
• Power Supply - Desktop/Plug-in: Input: 100~240V, 50/60Hz, output:19.5V/11.8A, DC Jack 5.5*2.5mmSupplier claim

Model

A10A

Minimum order

Confirmed with your quote

Sold by

unit

These details are supplier claims. We haven't tested them yet.

Shipping & ordering

You choose sea or air when you pay. Shipping, import duty and taxes are charged later at the agent's actual cost, never as part of the goods price.
